Specifications

Engine & Drivetrain

Cooling	Air
Cylinders Displacement	112cc
Drive System Type	2WD
Engine Type	4-Stroke Single Cylinder
Fuel System/Battery	Electronic Fuel Injection
Transmission/Final Drive	Automatic PVT F/N/R; O-ring Chain

Dimensions

Estimated Dry Weight	289 lb (131 kg)
Front Rack Capacity	15 lb (6.8 kg)
Fuel Capacity	2.9 gal (7.8 L)
Ground Clearance	3.5 in (8.9 cm)
Overall Vehicle Size (L x W x H)	61.75 x 36.75 x 38.5 in (156.8 x 93.3 x 97.8 cm)
Person Capacity	1
Rear Rack Capacity	30 lb (13.6 kg)
Seat Height	27 in (68.6 cm)

Brakes

Front/Rear Brakes	4-Wheel Drum
Parking Brake	Lockable Hand Lever

Additional Specifications

Color / Graphics	Velocity Blue
Instrumentation	N/R Light
Lighting	Dual LED Front Running Lights, Single Rear Brakelight/Taillight
Other Standard Features	Safety Flag, Parent-Adjustable Speed Limiter, 1 Color Matched Youth Helmet, Training DVD, Safety Tether
Speed Limiting	The speed of this vehicle is restricted to under 15 MPH (24 km/h) at manufacture. The speed limiting device may be adjusted by supervising adults when they determine that their child is capable of handling additional speed. The unrestricted top speed for this model is 30 MPH (48 km/h)

Tires / Wheels

Front Tires	19 x 7-8 Duro
Rear Tires	18 x 9.5-8 Duro
Wheelbase	41.5 in (105.4 cm)
Wheels	Stamped Steel

Suspension

Front Suspension	Single A-Arm with 5 in. (12.7 cm) Travel
Rear Suspension	Mono-Shock Swingarm with 6 in (15.2 cm) Travel

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
