Specifications

Engine & Drivetrain

Cooling	Liquid
Cylinders Displacement	2 / 850cc
Drive System Type	One Touch On-Demand AWD/2WD
Engine Braking System (EBS)	Equipped
Engine Type	ProStar 4-Stroke SOHC Twin Cylinder
Fuel System/Battery	Electronic Fuel Injection / 400 CCA
Horsepower	78 HP
Transmission/Final Drive	Automatic PVT P/R/N/L/H In-line Shifting

Dimensions

Estimated Dry Weight	804 lb (365 kg)
Front/Rear Rack	120 lb /240 lb (55 kg / 110 kg)
Fuel Capacity	5.25 gal (19.9 L)
Ground Clearance	11.25 in (28.5 cm)
Overall Vehicle Size (L x W x H)	84.3 x 48.2 x 48.8 in (214 x 123 x 124 cm)
Payload Capacity	575 lb (261 kg)
Person Capacity	2
Seat Height	35.75 in (90.8 cm)
Wheelbase	57 in (144.8 cm)

Brakes

Brake System Type	Single Lever 3-Wheel Hydraulic Disc w/ Hydraulic Rear Foot Brake
Parking Brake	Park In-Transmission / Lockable Hand Lever

Additional Specifications

Cargo System	4 Gal (15 L) Front Dry Storage 2 Gal (8 L) Rear Storage
Front Suspension	Straight Dual A-Arm, 9 in. (22.9 cm) Travel
Hitch Towing Rating	1,500 lb (680 kg)
Hitch Type	Standard 1.25 in (3.2 cm) Receiver
Instrumentation	All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet
Lighting	50w High Beam, Dual 50w Low Beam Headlights
Other Standard Features	Painted Plastics
Rear Suspension	Straight Dual A-Arm, IRS 10.25 in. (26 cm) Travel

Tires / Wheels

Electronic Power Steering	Multi Select EPS
Front Tires	26 x 8 CST
Rear Tires	26 x 10 CST
Wheels	14 in. (35.6 cm) Aluminum

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
